MA5608T GPON OLT
MA5608T is a compact, high-performance Mini OLT designed for small-capacity FTTx deployment scenarios. It integrates aggregation switch and edge router functionality into a single platform, supporting GPON, EPON, and 10G PON access with carrier-grade reliability and smooth evolution to 10G/40G PON.
Category: xPON OLT · Model: MA5608T
Key Features
- Convergence and Access Integration.
- Carrier-Grade High Reliability.
- Multi-Scenario Access.
- Smooth Evolution Path.
- Comprehensive QoS Guarantee.
- Energy-Efficient Design.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | MA5608T |
| Service Slots | 2*service board slots + 2*control board slots+1*power board slot |
| Control and uplink board | 2*MCUD of control and uplink integreated board (MCUD1 10G Uplink for Option) |
| Power board | 1*MPWD AC & DC Power Board or 1* MPWC Dual DC power board |
| Service baord | GPON: GPBD, GPBH, GPFD, XGBD / EPON: EPBD, EPSD, EPFD, XEBD |
| Max GPON Ports | 32 |
| Backplane Switching Capacity | 720 Gbit/s |
| Maximum ONT/ONU Support | Up to 4,096 ONTs (with 1:128 split ratio) |
| Power comsumption | < 110W (typical configuration) |
| Dimension | 2U ( 442mm * 244.5mm*88.1mm ) |
| Weight (empty chassis) | 3.55 kg |
| Operating Temperature | -40°C to +65°C |
| Operating Humidity | 5% RH to 95% RH (non-condensing) |
Specifications and variant information reflect the published catalog. Confirm the exact model, optional features and compatibility with FOT before ordering.
Typical Applications
Designed for compact deployment scenarios including FTTH, FTTB, FTTC, mobile backhaul, and enterprise private line access where space is limited but high performance is required.
Related Products
- One PON Port GPON OLT
- 8PON Ports XG/XGS-PON OLT
- 2PON Ports XG/XGS-PON OLT
- One PON Port GPON OLT with ODN
Related Solutions & Guides
Equipment Buyer Questions
What is MA5608T GPON OLT used for?
Designed for compact deployment scenarios including FTTH, FTTB, FTTC, mobile backhaul, and enterprise private line access where space is limited but high performance is required.
Which specifications should I check for MA5608T GPON OLT?
The listed specifications include Model: MA5608T; Service Slots: 2*service board slots + 2*control board slots+1*power board slot; Control and uplink board: 2*MCUD of control and uplink integreated board (MCUD1 10G Uplink for Option); Power board: 1*MPWD AC & DC Power Board or 1* MPWC Dual DC power board. Review the complete table and confirm your required configuration with FOT.
Is compatibility with my existing network guaranteed?
Compatibility depends on your existing equipment, firmware, interfaces and service configuration. Share your OLT/ONT or network equipment models with FOT for confirmation before deployment.
How can I request a quote for MA5608T GPON OLT?
Email sales@fiberoptictel.com with the product name, model MA5608T, quantity and required configuration. Ask for confirmation of pricing, availability and lead time.
