IMOT-1310P Series 1310nm Optical Transmitter
1U rack-mountable 1310nm optical transmitter with pluggable dual power supply and AGC function. Features original system optimal control technology and RF pre-distortion for excellent CTB/CSO/SBS performance. Ideal for long-distance transmission of images, data, and compressed digital signals in CATV and telecom networks.
Category: CATV Optical Equipment
Key Features
- High performance with original system optimal control technology and RF pre-distortion.
- AGC function with automatic gain control.
- Modular design with replaceable circuits.
- Pluggable dual power supply with 90–265V AC automatic switching.
- Intelligent monitoring with microprocessor and LCD display.
- Network management with RJ45 port for remote control.
Technical Specifications
| Parameter | Specification |
|---|---|
| Wavelength | 1310 ± 10 nm |
| Fiber Connector | FC/APC, SC/APC, SC/UPC (optional) |
| Working Bandwidth | 47–750 (862) MHz |
| Channels | 84 |
| CNR | ≥51 dB |
| CTB | ≥65 dBc |
| CSO | ≥-60 dBc |
| RF Input Level | 75–85 dBμV |
| RF Input Return Loss | ≥16 dB |
| Flatness | ±0.75 dB |
| Power Consumption | ≤50 W |
| Power Supply | 90–265V AC pluggable dual |
| Dimension | 19" × 11" × 1.75" |
| Working Temperature | -20°C to +85°C |
| Storage Temperature | -40°C to +85°C |
Listed Model Variants
| Model | Listed Optical Output |
|---|---|
| IMOT-1310P-04 | 4 mW (6 dBm) |
| IMOT-1310P-06 | 6 mW (7.8 dBm) |
| IMOT-1310P-08 | 8 mW (9 dBm) |
| IMOT-1310P-10 | 10 mW (10 dBm) |
| IMOT-1310P-12 | 12 mW (10.8 dBm) |
| IMOT-1310P-14 | 14 mW (11.5 dBm) |
| IMOT-1310P-16 | 16 mW (12 dBm) |
| IMOT-1310P-18 | 18 mW (12.6 dBm) |
| IMOT-1310P-20 | 20 mW (13 dBm) |
| IMOT-1310P-22 | 22 mW (13.4 dBm) |
| IMOT-1310P-24 | 24 mW (13.8 dBm) |
| IMOT-1310P-26 | 26 mW (14 dBm) |
| IMOT-1310P-28 | 28 mW (14.5 dBm) |
Specifications and variant information reflect the published catalog. Confirm the exact model, optional features and compatibility with FOT before ordering.
Typical Applications
Ideal for long-distance transmission of images, data, and compressed digital signals in CATV and telecom networks.
